Access Point Engenius EWS377-FIT 4×4 Managed Indoor Wireless Access Point features 802.11ax technology, which deepens and extends the capabilities of Wi-Fi and harnesses EnGenius enterprise-level management and AP features for use in high-capacity environments.The sleek, low-profile AP is loaded with new hardware components to run more efficiently and consume less power for maximum theoretical speeds of 1,148 Mbps (2.4 GHz frequency) and 2,400 Mbps (5 GHz frequency). To give your network elevated security, WPA3/WPA2-PK (AES) makes connecting client and IoT devices more secure and easier.
Liên Hệ[Giá đã bao gồm VAT]
Wifi EWS377-FIT Dual Band
Mã SP: EWS377-FIT
Lượt xem: 192
MÔ TẢ SẢN PHẨM:
- Dual concurrent 802.11ax architecture & backward-compatible with 11ac/a/b/g/n client devices
- WPA3 & WPA2-AES authentication support
- 5 dBi integrated 4×4 antenna
- Supports up to 2,400 Mbps in the 5GHz frequency band & 1,148 Mbps in the 2.4GHz frequency band
- 2.5 Gigabit Ethernet PoE port for flexible power options
- Local and remote management over Fitcon controller without fees
- Choice of AP and WDS modes to meet your management & deployment requirements
- Made in Taiwan
Kho hàng: Còn hàng
Bảo hành: theo tiêu chuẩn nhà sản xuất
Liên Hệ[Giá đã bao gồm VAT]
| Technical Specifications | Management Features |
| Standards | Deployment Options |
| 802.11a/b/g/n/ac/ax | Stand-Alone (Individually Managed) |
| Antenna | FitXpress |
| 4 x 2.4 GHz: 5 dBi | FitController |
| 4 x 5 GHz: 6 dBi | Environmental & Physical |
| Physical Interface | Temperature Range |
| 1 x 10/100/1000/2500 BASE-T | Operating: 32ºF~104ºF (0 ºC~40 ºC) |
| DC12V | Storage: -40 ºF~176 ºF (-40 ºC~80 ºC)C |
| Yes, proceed reset and reboot when pushing this button | Humidity (non-condensing) |
| LED Indicators | Storage: 90% or less |
| 1 x Power | Dimensions & Weight |
| 1 x LAN | EWS377-FIT Device |
| 1 x 2.4 GHz | Length: 205 mm |
| 1 x 5 GHz | Width: 205 mm |
| Power Source | Height: 33 mm |
| PoE 802.3at | Package Contents |
| DC12V | 1 – EWS377-FIT Indoor Access Point |
| Maximum Power Consumption | 1 – Ceiling Mount Base (9/16” Trail) |
| 19.5W | 1 – Ceiling Mount Base (15/16” Trail) |
| Wireless & Radio Specifications | 1 – Ceiling and Wall Mount Screw Kit |
| Operating Frequency | 1 – Quick Installation Guide |
| Dual-Radio Concurrent 2.4 GHz & 5 GHz | Compliance |
| Operation Modes | FCC |
| Managed mode: AP, AP Mesh, Mesh | CE |
| Frequency Radio | IC |
| 2.4 GHz: 2400 MHz ~ 2482 MHz | UCKA |
| 5 GHz: 5150 MHz ~ 5250 MHz, 5250 MHz ~ 5350 MHz, 5470 MHz ~ 5725 MHz, 5725 MHz ~ 5850 MHz | |
| Transmit Power | |
| Up to 23 dBm on 2.4 GHz | |
| Up to 23 dBm on 5 GHz | |
| (Maximum power is limited by regulatory domain) | |
| Tx Beamforming (TxBF) | |
| Radio Chains | |
| 4 × 4:4 | |
| SU-MIMO Capability | |
| Four (4) spatial stream Single User (SU) MIMO for up to 1148 Mbps wireless data rate with HE40 bandwidth to a 4×4 wireless client device under the 2.4GHz radio. | |
| Four (4) spatial stream Single User (SU) MIMO for up to 2400 Mbps wireless data rate with HE80 to a 4×4 wireless device under the 5GHz radio. | |
| MU-MIMO Capability | |
| Four (4) spatial streams Multiple (MU)-MIMO up to 2,400 Mbps wireless data rate for transmitting to four (4) streams MU-MIMO 11ax capable wireless client devices under 5GHz simultaneously. | |
| Four (4) spatial streams Multiple (MU)-MIMO up to 1,148 Mbps wireless data rate for transmitting to four (4) streams MU-MIMO 11ax capable wireless client devices under 2.4GHz simultaneously. | |
| Supported Data Rates (Mbps): | |
| 802.11ax: | |
| 2.4 GHz: 9 to 1,148 (MCS0 to MCS11, NSS = 1 to 4) | |
| 5 GHz: 18 to 2,400 (MCS0 to MSC11, NSS = 1 to 4) | |
| 802.11b: 1, 2, 5.5, 11 | |
| 802.11a/g: 6, 9, 12, 18, 36, 48, 54 | |
| 802.11n: 6.5 to 600 (MCS0 to MCS31) | |
| 802.11ac: 6.5 to 1,733 (MCS0 to MCS9, NSS = 1 to 4) | |
| Supported Radio Technologies | |
| 802.11ax: Orthogonal Frequency Division Multiple Access(OFDMA) | |
| 802.11a/g/n/ac: Orthogonal Frequency Division Multiple (OFDM) | |
| 802.11b: Direct-sequence spread-spectrum (DSSS) | |
| Channelization | |
| 802.11ax supports high efficiency throughput (HE) —HE 20/40/80 MHz | |
| 802.11ac supports very high throughput (VHT) —VHT 20/40/80 MHz | |
| 802.11n supports high throughput (HT) —HT 20/40 MHz | |
| 802.11n supports high throughput under the 2.4GHz radio –HT40 MHz (256-QAM) | |
| 802.11n/ac/ax packet aggregation: A-MPDU, A-SPDU | |
| Supported Modulation | |
| 802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM | |
| 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM | |
| 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM | |
| 802.11b: BPSK, QPSK, CCK | |
| Max Concurrent User | |
| 127 per radio |
